Description
Ricoh SP-2230 Image Scanner
Details:
Scanning speeds of up to 30 pages per minute
80 page automatic document feeder (ADF)
Supports USB 3.
2 (Typc C)
Compact size: 292 x 163 x 150mm
Integrated TWAIN & ISIS driver connectivity-works with hundreds of scanning software solutions
The SP-2230 focuses on the essential scanning functions businesses rely on most, providing a practical and cost-effective solution for document digitization.
fi Series Proven Reliability
Inherits the document protection systems and stable operation engineered into RICOH’s premium fi Series scanners at an everyday price.
Easy and Reliable Scanning
Intuitive one-touch scanning and customizable image processing with PaperStream ClickScan
Versatile Document Handling
Standard pages, mixed batches, A3 bi-fold documents, envelopes, multi-layer documents, and plastic cards — all in one scanner.
SPECIFICATIONS
Scanning Speed30 ppm / 60 ipm
Resolution – Optical600 DPI
Simplex / DuplexDuplex
ADF Capacity80 Sheets
Expected Daily Volume4,500 sheets.
Multifeed DetectionOverlap detection, Length detection
Weight3.3 kg (7.3 lb)
Dimension292 x 163 x 150 mm
Scanner Type
ADF (Automatic Document Feeder)/Manual Feed,
Duplex
Scanning Speed*1
(A4 Portrait)
(Color*2/Grayscale*2/
Monochrome*3)
Simplex: 30 ppm (200/300 dpi)
13 ppm (400/600 dpi)
Duplex : 60 ipm (200/300 dpi)
26 ipm (400/600 dpi)
Image Sensor Type CIS x 2 (front x 1, back x 1)
Light Source RGB LED x 2 (front x 1, back x 1)
Optical Resolution 600 dpi
Output Resolution*4
(Color/Grayscale/
Monochrome)
50 to 600 dpi (adjustable by 1 dpi increments),
1,200 dpi (driver)*5
Output Format Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
Background Colors White
Document Size
Maximum*6 215.9 x 355.6 mm (8.5 x 14 in.)
Minimum 50.8 x 50.8 mm (2.0 x 2.0 in.)
Long Page Scanning*7 6,096 mm (240 in.) (up to 200 dpi)
Paper Weight (Thickness)
Paper 27 to 413 g/m2
(7.2 to 110 lb)*8
Plastic Card*9 1.4 mm (0.055 in.) or less
ADF Capacity*10*11 80 sheets (A4 80 g/m2
or Letter 20 lb)
Expected Daily Volume*12 4,500 sheets
Multifeed Detection Overlap detection (Ultrasonic sensor), Length detection
Paper Protection Lag detection
Interface
USB
USB 3.2 Gen1x1/USB 3.0/USB 2.0/USB 1.1
(Connector Type: Type-C)
Power Requirements AC 100 to 240 V ±10%
Power Consumption
Operating Mode 15 W
Sleep Mode 1.4 W or less
Auto Standby (Off)
Mode
0.2 W or less
Operating Environment
Temperature 5 to 35°C (41 to 95°F)
Relative Humidity 15 to 80%
Environmental Compliance ENERGY STAR, RoHS, EPEAT
Dimensions*13
(Width x Depth x Height) 292 x 163 x 150 mm (11.5 x 6.4 x 5.9 in.)
Weight 3.3 kg (7.3 lb)
Supported
Operating System
Windows 11*14, Windows 10*15
, Windows Server
2025, Windows Server 2022, Windows Server
2019, Windows Server 2016
Software/Drivers*16
PaperStream IP Driver (TWAIN/TWAIN x64), WIA
Driver*17
, PaperStream Capture Series, PaperStream
ClickScan, Searchable PDF Option, Software
Operation Panel, Error Recovery Guide, PaperStream
Central Admin, SP Series Online Update, Manual
Installer
Image Processing Functions
Multi image output, Automatic color detection,
Blank page detection & deletion, Dynamic threshold
(iDTC), Advanced DTC, SDTC, Error diffusion, Dither,
Static threshold, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom),
sRGB output, Hole punch removal, Split image,
De-Skew, Edge filler, Edge repair, Vertical streaks
reduction, Cropping, Automatic rotation, Barcode
detection (1D&2D), Background pattern removal,
Front/Back merging
Included Items ADF paper chute, AC cable, AC adapter, USB 2.0
cable
Warranty: 1 year
