Description
Ubiquiti UAP-AC-HD UniFi WiFi Legacy Access Point
SPECIFICATIONS
Overview
Dimensions
⌀220 x 48.1 mm (⌀8.7 x 1.9″)
WiFi Standard
WiFi 5
Spatial Streams
8
Coverage Area
140 m² (1,500 ft²)
Max. Client Count
500+
Uplink
GbE
Mounting
Ceiling, Wall (Pro Mount Included)
Power Method
PoE+
Performance
MIMO
5 GHz
4 x 4 (DL MU-MIMO)
2.4 GHz
4 x 4 (DL MU-MIMO)
Max. Data Rate
5 GHz
1.7 Gbps (BW80)
2.4 GHz
800 Mbps (BW40)
Antenna Gain
5 GHz
4 dBi
2.4 GHz
3 dBi
Max. TX Power
5 GHz
25 dBm
2.4 GHz
25 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80)
802.11n
6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)
Features
Wireless Meshing
✓
Band Steering
✓
802.11v BSS Transition Management
✓
802.11r Fast Roaming
✓
802.11k Radio Resource Management (RRM)
✓
Advanced Radio Management
✓
Passpoint (Hotspot 2.0)
✓
Captive Hotspot Portal
Custom Branding Landing Page
✓
Voucher Authentication
✓
Payment-Based Authentication
✓
External Portal Server Support
✓
Password Authentication
✓
Guest Network Isolation
✓
Private Pre-Shared Key (PPSK)
✓
WiFi Speed Limiting
✓
Client Device Isolation
✓
WiFi Schedules
✓
RADIUS over TLS (RadSec)
✓
Dynamic RADIUS-assigned VLAN
✓
Hardware
Max. Power Consumption
17W
Includes PoE Adapter
✓
Supported Voltage Range
44–57V DC
Networking Interface
(2) GbE RJ45 ports
Weight
Device: 700 g (1.5 lb) With mount: 830 g (1.8 lb)
Management
Ethernet WiFi
LEDs
System
Status
Channel Bandwidth
HT 20/40, VHT 20/40/80 (MHz)
Operating Frequency
US/CA: 2400 – 2472 MHz U-NII-1: 5150 – 5250 MHz U-NII-2A: 5250 – 5350 MHz U-NII-2C: 5470 – 5725 MHz U-NII-3: 5725 – 5850 MHz Worldwide: 2400 – 2483.5 MHz 5150 – 5850 MHz
Ambient Operating Temperature
-10 to 70° C (14 to 158° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
✓
Certifications
CE, FCC, IC, Anatel
Software
Application Requirements
UniFi Network
Version 6.0.45 and later
