Description
Hikvison DS-D5C86RB/B2L 86-inch 4K Interactive Display
- UHD 4K display with a resolution of 3840 × 2160 and 480 nits brightness.
- Anti-Glare and Anti-Fingerprint design to ensure smooth interaction.
- Dual systems of Android and Windows (optional with 195×30×180mm OPS) saving cost and easy to use, video conferencing software is recommended to run on the Windows system.
- Supports up to 50-point multi-touch interaction with smooth and responsive writing.
- Built-in network switch chip eliminates the need for an external network switch.
- Multi-button front design for convenient classroom use.
- Durable all-in-one design with tempered safety glass and intelligent thermal management.
- Built-in Android 16 operating system with EDLA certification.
- Dual full-function USB Type-C ports, supporting up to 100W total power delivery and DisplayPort 1.2 input.
- Built-in sensors for ambient light, humidity, and temperature monitoring.
SPECIFICATIONS
Product Model
Product ModelDS-D5C86RB/B2L
Display
Screen Size 86 inch
BacklightDLED
Pixel Pitch0.164 (H) × 0.493 (V) mm
Resolution3840 × 2160 @60 Hz
Brightness480 cd/m² (Typ.)
Color Depth10 bit (8 bit + FRC)
Display Color1.07 G
Response Time5 ms
Panel TypeVA
Contrast Ratio
5000:1 (Static)
30,000:1 (Dynamic)
Color Gamut72% NTSC (CIE1931) (Typ.)
Refresh Rate60 Hz
Viewing Angle178° (H)/178° (V)
Aspect Ratio16:9
Surface Hardness
9H (Pencil)
7 (Mohs)
Surface GlassAnti-Glare & Anti-Fingerprint glass
Surface Haze25% Haze
Glass Bonding MethodZero Lamination
Display Area1895.04 × 1065.96 mm
Working Duration7 × 16 H
Transmittance88% ± 3
Lifespan50,000 hours
Touch
TypeInfrared Touch Screen
Touch PointUp to 50-point multi-touch
Touch Response Time≤ 2 ms
Minimum Touch Object≥ 1.5 mm (≥ 90% touching area)
Touch Precision± 0.5 mm (≥ 90% touching area)
Touch Resolution32768 × 32768
Built-in System
Operation SystemAndroid 16.0
Memory8 GB (Optional 16 GB) + Max 16 GB Virtual RAM
Built-in Storage128 GB (Optional 256 GB)
ProcessorQuad-core Cortex-A76 × 4（2.4 GHz）and quad-core Cortex-A55 × 4（1.8 GHz）
GPUMali-G610 MC4
HDCP Version2.3 & 2.0 & 1.4
NPU6TOPs
Camera
Pixel48 MP for Photos & 8 MP for Video
Camera FunctionIntelligent switching between Android, OPS, and external PC systems.
Field Angle93.4° (diagonal), 84.5° (horizontal), 54.1° (vertical)
Distortion≤ 2.5%
Camera Resolution RatioUp to 4K
Microphone
SpecificationOmni-directional 8-array layout
Mic FunctionEcho reduction and smart noise-cancellation
Voice Distance12 m
Sampling Rate32 K
Mic Depth16 bit
Internal Function
LoudspeakerBuilt-in 2 × 20 W + 25 W loudspeaker;
Language SupportedSimplified Chinese, German, Italian, Arabic, Portuguese,
Dutch, French, Indonesian, Thai, Vietnamese, Japanese, Spanish, English, Czech, Danish, Hungarian,
Polish, Turkish, Russian, Romanian, Slovak, Korean, Uzbek, Bulgarian, Greek, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Hebrew, Ukrainian, Traditional Chinese (HK), Traditional Chinese (TW),
Hindi, Latvian, Kazakh, Nepali
BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.4
NFC
Support card reader
13.56 MHz, (ISO 14443A/ ISO 14443B/ ISO 15693)
Light SensorYes
Humidity and Temperature SensorRelative humidity accuracy: up to ± 1.5 %RH; Temperature accuracy: up to ± 0.1 °C
Image Processing TechnologySupport 3D digital noise reduction, face detection, automatic white balance,
automatic purple fringing correction, automatic defogging, and shadow correction.
Audio Processing TechnologySupport dereverberation, adaptive noise reduction,
adaptive non-stationary noise reduction, adaptive echo cancellation, automatic gain control,
automatic electrical level control, sound source localization, speech dynamic detection,
digital beam forming, speech detection.
AI FunctionAI Assistant, AI Identify, and AI Notes. Free for a 1-year validity period with 6,000 minutes for AI Notes.
WhiteboardBuilt-in whiteboard supports handwriting recognition, graphics recognition, document insertion, and more.
ScreenCastBuilt-in WonderCast software supports screen casting for up to 9 devices simultaneously.
Interface
Video & Audio Input
HDMI 2.1 TMDS × 3（Front x 1; Rear x 2; Support HDCP2.3 & 2.0 & 1.4; Support HDMI CEC protocol）
VGA × 1（Rear）
Audio × 1（Rear）
Video & audio output
HDMI 2.1 TMDS × 1（Rear）
Audio × 1（Rear）
SPDIF × 1（Rear）
Control interface
TOUCH-USB 3.0 × 1（Front × 1）
TOUCH-USB 2.0 × 2（Rear × 2）
RS232 × 1（Rear）
Network Interface
LAN (1000 Mbps) × 2（Rear）
Wi-Fi AP & Station, 2.4 G/5 G
Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP
Data Transmission Interface
USB 3.0 × 4（Front × 2; Rear × 2）
USB 2.0 × 1（Rear）
Type-C × 2 (Front × 1; Rear × 1; Support USB 2.0, 100 W charging functions, DP IN 1.2 )
Power
Power Supply100 to 240 VAC, 50/60 Hz
Standby Consumption≤ 0.5 W
Average Consumption< 274 W
Working Environment
Working Temperature0 °C to 40 °C (32 °F to 104 °F)
Working Humidity10%~90% RH
General
VESA800 mm × 600 mm (4 × M8-25 mm)
AccessoryWall mount bracket, hook, user manual, touch writing pen, packing list, 3 M touch USB cable, 3.5 M HDMI cable (2.0), 3 M power cable, remote control, screen cleaning cloth.
Package Dimensions (W × H × D)2157 × 1345 × 223 mm
Net Weight58.9 ± 0.5 kg
Gross Weight78.9 ± 0.5 kg
Product Dimensions （With Wall Attachment）1960.4 × 1173.7 × 106.4mm
Product Dimensions （Without Wall Attachment）1960.4 × 1173.7 × 82.4 mm
CertificationCE, CB, ANATEL, IP5X, LOA, REACH, EDLA, Energy Star, SUBTEL, TUV Low Blue Lgiht, MIC, CFP(ISO 14067/ISO14040/EN50693)
