Description
Model :
OLS3000ERT2UA
VA 3000 Watts 2700 Output Voltage ( Vac ) 208 ± 1 % / 220 ± 1 % / 230 ± 1 % / 240 ± 1 % Half Load Runtime ( min ) 13.1 Outlets IEC C19 x 2 / IEC C13 x 8
ECO Mode
Pure Sine Wave Output
Color LCD Panel
Variable Speed Fans
CyberPower OLS3000ERT2UA is a high-performance UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It’s typically integrated in the back office, server room, and data center environment. The UPS features color LCD panel for users to monitor power system and configure settings easily. This model can be used with compatible Extended Battery Modules (EBM) to prolong system runtime during power interruption. The variable speed fans provide automatic thermal management based on power load to reduce noise and provide greater comfort for users. The product also supports power management software to perform real-time monitoring and remote management.
Features
- Online (Double Conversion) UPS Topology
- Generator Compatible
- Zero Transfer Time
- Extended Battery Module Auto-detection
- Critical/Non-critical Load Outlets
- Phone/Fax/Modem/DSL/Network Protection
- Variable Speed Fans
- PowerPanel Management Software
- Rack/Tower Convertible Configurations
- ECO Mode
- Overload Protection
- Smart Battery Management (SBM)
- Surge and Spike Protection
- EMI and RFI Filtration
- Color LCD Panel
- Emergency Power Off (EPO) Port
- SNMP/HTTP Remote Management Capability (Optional)
SPECS .
General
Phase Single Phase
Form Factor Rackmount, Tower
UPS Topology Online Double Conversion
Energy Saving Technology ECO Mode Efficiency ＞ 95%
Active PFC Compatibility Yes
Input
Generator Compatibility Yes
Nominal Input Voltage ( Vac ) 230 ± 10%
Input Voltage Range ( Vac ) 190 ~ 300
Adjustable Voltage Range ( Vac )
| 0~30% Load for 80 ~ 300 Vac |
| 0~60% Load for 140 ~ 300 Vac |
| 0~80% Load for 160 ~ 300 Vac |
| 0~100% Load for 190 ~ 300 Vac |
Input Frequency ( Hz )
50 ± 10
60 ± 10
Input Frequency Detection Auto-sensing
Rated Input Current ( A ) 13
Input Power Factor 0.99
Input Connector Type
| IEC C20 | |
Detachable Power Cord Plug Type
| Schuko x 1 | |
Power Cord Length (ft.) 5
Power Cord Length (m.) 1.5
Output
Capacity (VA) 3000
Capacity (Watts) 2700
On Battery Waveform Pure Sine Wave
On Battery Voltage(s) ( Vac )
| 208 ± 1 % |
| 220 ± 1 % |
| 230 ± 1 % |
| 240 ± 1 % |
Output Voltage Setting
| Configurable |
On Battery Frequency ( Hz )
| 50 ± 0.5% |
| 60 ± 0.5% |
Output Frequency Setting
| Configurable |
Power Factor
| 0.9 |
ECO Mode Voltage Tolerance
| ± 15 % |
Overload Protection
| Internal Current Limiting, Circuit Breaker, Fuse |
Overload Protection (Line Mode)
| 110~120% Load for 1 min, ＞120% Load Immediately |
Overload Protection (Battery Mode)
| 110~120% Load for 10 sec, ＞120% Load Immediately |
Overload Protection (Bypass Mode)
| ＞130% Load Immediately |
Crest Factor
| 3 : 1 |
Harmonic Distortion (Linear Load)
| THD＜3% |
Harmonic Distortion (Non-linear Load)
| THD＜5% |
Internal Bypass
| Automatic Bypass, Manual Bypass |
Outlet(s) – Total
| 10 |
Outlet Type
| IEC C19 x 2 | |
| IEC C13 x 8 | |
Outlet(s) – Battery & Surge Protected
| 10 |
Outlet(s) – Critical Load (CL)
| 6 |
Outlet(s) – Non-critical Load (NCL)
| 4 |
Typical Transfer Time ( ms )
| 0 |
Battery
Runtime at Half Load ( min )
| 13.1 |
Runtime at Full Load ( min )
| 4.2 |
Typical Recharge Time ( Hours )
| 4 |
Maximum Charging Current ( A )
| 1.5 |
Start On Battery
| Yes |
Smart Battery Management (SBM)
| Yes |
User-replaceable
| Yes |
Hot-swappable
| Yes – Qualified Personnel Only |
Replacement Battery Pack (RBP)
| RBP0158 |
Replacement Battery Pack (RBP) Quantity ( pcs )
| 1 |
Battery Quantity (Each RBP) ( pcs )
| 6 |
Battery Voltage (Each RBP) ( V )
| 72 |
Compatible Extended Battery Module (EBM)
| BPSE72V40ART2U |
Extended Battery Module Auto-detection
| Yes |
Max. EBM Quantity ( pcs )
| 3 |
Surge Protection & Filtering
Surge Suppression ( Joules )
| 388 |
EMI/RFI Filtration
| Yes |
Phone/Network Protection RJ11/RJ45 (Combo)
| 1-in, 1-out |
Management & Communications
LCD Panel
| Yes |
LCD Types
| Color LCD |
LCD Orientation
| Rotatable LCD – Manual |
LCD Information Display
| Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log |
LCD Setting & Control
| Mode Setting, Alarm Setting, Input & Output, Battery Setting |
HID Compliant USB Port(s)
| 1 |
Dry Contact (with Relay)
| Yes |
Emergency Power Off (EPO) Port
| Yes |
Audible Alarms
| Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery |
Management Cable ( pcs )
| Power Cord x2, USB Cable x1 |
Power Management Software
| PowerPanel Business (Recommended) |
SNMP/HTTP Remote Monitoring
| Yes – with optional RMCARD205 |
Physical
Enclosure Construction
| Metal |
Color
| Black |
Rackmount Rail
| Yes |
Rackmount Ears
| Yes |
Physical Size – UPS Module
Dimensions (WxHxD) (in.)
| 17.24 x 3.46 x 24.2 |
Dimensions (WxHxD) (mm.)
| 438 x 88 x 610 |
Weight (lbs.)
| 60 |
Weight (kg.)
| 27.2 |
Installed Rack Height ( U )
| 2 |
Shipping Dimensions
Dimensions (WxHxD) (in.)
| 21.3 x 9 x 28.7 |
Dimensions (WxHxD) (mm.)
| 540 x 230 x 730 |
Weight (lbs.)
| 70.5 |
Weight (kg.)
| 32 |
Environmental
Operating Temperature (°F)
| 32 ~ 104 |
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
| 5 ~ 95 |
Operating Elevation ( feet/meters )
| 0-4,921 feet (0-1,500 meters) |
Storage Temperature (°F)
| -4 ~ 122 |
Storage Temperature (°C)
| -20 ~ 50 |
Storage Relative Humidity (Non-condensing) ( % )
| 10 ~ 90 |
Storage Elevation ( feet/meters )
| 0-4,921 feet (0-1,500 meters) |
Online Thermal Dissipation ( BTU/hr )
| 911 |
Variable Speed Fans
| 20 steps automatically |
Audible Noise at 1.5M from Surface of Unit ( dBA )
| 45 |
Certifications
Certifications
| CE, EAC, TISI |
RoHS
| Yes |
