• 3.5″ SATA HDD

Supported OS

• Windows 10, 11, Server 2016, Server 2019, Server 2022

• macOS

• UNIX, Linux, and BSD

Supported Languages

Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย

Supported Browsers

• Firefox

• Chrome

• Safari

• Microsoft Edge

Network Protocols

CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog

Connection and transmission

• TCP/IP (IPv4 & IPv6)

• Jumbo Frame (MTU)

• VLAN

• EZ Connect

• Wireless Network

• DDNS and EZ-Router

• Supports Wake-on-LAN (WOL)

• Supports Wake-on-WAN (WOW)

File System

• Internal Disk: EXT4 ,Btrfs

• External Disk: FAT32, NTFS, EXT3, EXT4, HFS+, exFAT

File Explorer

• Web-based File Management

• ISO File Mounting

• Share Links

• Task Monitor

• Browse Files on Local PC

• Thumbnail Previews

• Data Access via External Optical Drive

• Supports video playback

Network Recycle Bin

• Share folder-based

• Maintains original directory structure and file permission

• On-click restore

• Supports scheduled emptying

• Filtering rules

  1. File size

  2. File extension

• Deletion Settings

  1. File size

  2. File date

Supported RAID levels

• Single

• JBOD

• RAID 0

• RAID 1

• RAID 5

• RAID 6

• RAID 10

Supported RAID migration methods

• Single to RAID 1

• Single to RAID 5

• Single to RAID 6

• Single to RAID 10

• RAID 1 to RAID 5

• RAID 1 to RAID 6

• RAID 1 to RAID 10

• RAID 5 to RAID 6

RAID levels supporting storage expansion by complete drive replacement

• RAID 1

• RAID 5

• RAID 6

• RAID 10

RAID levels supporting storage expansion by drive addition

• RAID 5

RAID spare drive support

• RAID 1

• RAID 5

iSCSI/IP-SAN

• Maximum Targets: 256

• Maximum LUNs: 256

• Maximum Snapshot Versions of a Single LUN: 256

• Target Masking

• LUN Mapping

• ISO File Mounting

• Supports MPIO

• Persistent (SCSI-3) Reservations

Disk Management

• Scheduled Bad Block Scans

• Scheduled S.M.A.R.T Scans

Access Control

• Maximum Number of Users: 4096

• Maximum Number of Groups: 512

• Maximum Number of Shared Folders: 512

• Maximum Number of Concurrent Connections: 512

• Supports Windows Active Directory

• Supports Windows Active Directory / LDAP

ACL

• Provides both Windows ACL and Linux ACL permission configuration methods

• Can enable Windows ACL for specific shared folders

• Comprehensive support for Windows’ 13 types of advanced permission settings

• Can view Windows ACL permission settings from within ADM

• Supports local users and groups

• Exclusive permission reset function allows users to quickly restore default permissions

System Administration

• Log Type: System Log, Connection Log, File Access Log

• Real-time Online User Monitor

• Real-time System Monitor

• User Quota

• Virtual Drive (ISO Mounting, Maximum 16)

• UPS Support

Security

• AES 256-Bit Encryption

• Firewall: Prevent Unauthorized Access

• Alert Notifications: E-mail, SMS

• Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH

• Built-in Hardware Encryption Engine

• RAID Scrubbing: detects the integrity and consistency of RAID 5 and RAID 6 drive data.

Network Defender

• Auto black list

• Trusted list

• Black/White list

  • Supports IP/IP range/geolocation

Backup Solutions

• Rsync (Remote Sync) Backup

• Cloud Backup

• FTP Backup

• External Backup

• EZ Sync

• SMB Backup

Snapshots

• Btrfs Snapshots

• 256 Snapshots

• iSCSI LUNs

ASUSTOR Hightlight

• System Migration

• EZ Connect

• Dr. ASUSTOR

• 2-way Backup

• Task Monitor

Eco-Friendly Design

• Auto-Standby for Both Internal and External Disks

• Auto Fan Control

• LED Night Mode

• Power Schedule: On, Off, Restart

Energy Control

• Configurable Disk Hibernation Wait Time
