Description

EVO PLUS tower

DSP CONTROLLED ON-LINE UPS

Warranty: 2-year warranty on UPS, 1 Year warranty on Battery. Carry into the service center, No onsite included

Online double conversion VFI protection from 1000VA to 3000VA
• Extreme battery lifetime thanks to:
– Wide input voltage tolerance (110-300V)
– Wide input frequency (44-66Hz)
– Intelligent battery management
• Optimized Output Power Factor 0.9
• Cold start to activate loads without mains
• Multiple operation modes to maximize energy efficiency
• Strong overload capability to improve Circuit Breaker’s selectivity
• Intuitive LCD interface provides clear information with easy-to-use navigation keys
• UPS management via RS232 port or USB port
• Multiple outlet types: IEC, Schuko, Universal for various output connections
• External Battery Connector for extended runtime capability
• Firmware upgradeable for updates and customization

TECH SPECS

MODEL EVO PLUS 2000
INPUT
Input Voltage 220/230/240Vac
Voltage Range** 110~300Vac
Phase Single Phase with Ground
Frequency Range 44~66Hz (Auto sensing)
Input Power Factor >0.98 @ 100% linear load

OUTPUT
Capacity 2000VA/1800W
Output Voltage 220/230/240 Vac (Settable)
Output Power Factor 0.9
Output Voltage Distortion <4% @ 100% Linear load <7% @ 100% non-linear load
Output Voltage Regulation ±1%
Frequency Range ±1Hz or ±3Hz (selectable)
Crest Factor 3:1
Transfer Time (AC to DC) 0ms
Output Waveform Pure SineWave

EFFICIENCY
Line Mode >90%
Eco Mode >98%

PHYSICAL
Dimension (WxHxD, mm) 192 x 250 x 386
Net Weight (kg) 16.0
Output Connections*** 4x Universal

BATTERY
Type Sealed Lead Acid Maintenance Free
Capacity Standard 12V/7AH or 12V/9AH (optional upon request)
Number of Battery 4
Rated Battery Voltage 48Vdc
Recharge Time (to 90%) 4 hours

FRONT PANEL
LCD Normal, Battery, Bypass, Self-Test, Battery Weak, Site Wiring Fault, Overload, Load/Battery Level
BUTTON (3 KEY) ON/Alarm Silence Button, OFF Button, Test/Level Button

ALARM
Audible or Visual Line failure/Battery low/Transfer to bypass/System fault
PROTECTION
Full protection Overload, Over Temperature, Short circuit, Deep discharge, Overcharge

FUNCTION
Multi-Mode
Normal/ECO/CVCF
DC Start Yes
ENVIRONMENT
Operation Temperature 0~40°C
Operation Humidity 0%~90% (without condensing)
Altitude 1000m without derating
Noise Level  50dBA @ 1 meter front

INTERFACE
Standard RS-232 and USB
Option 2nd RS232, 2nd USB, Dry contact card, SNMP/Web card, RS485
Compatible platforms
Microsoft Windows, Linux, Mac

STANDARDS & CERTIFICATIONS
Safety & EMC
IEC EN 62040-1, IEC EN 62040-2
Marks
CE
